Aikon F7 Mini 45A All-In-One Flight Controller

The Aikon flight controller is a new generation flight controller and ESC combination specifically designed for cinewhoops and other high-current applications. We've packed all the greatest features into one seamless flight experience.

What makes the Aikon AIO Mini amazing?

• 216mhz F7 processor
• Idependent FC and ESC PCBs for low noise
• 5 Software invertible hardware UARTS
• Onboard OSD and blackbox
• Software controlled VTX power switch (assigned to USER1 mode by default)
• Connectors for DJI-HD and RC link
• LED and buzzer outputs (LED pad doubles as PPM)
• On-board high overhead voltage regulators rated up to 6S (50v peak to handle voltage spikes)
• 3.3mm high current MOSFETs.
